Advertising Pylon, Shadow Design, LED Illuminated, H=2200 mm

Technical description | Features:

Material:

Construction made of galvanised steel and/or aluminium. Fronts colour silver. Lateral frame elaborated with a very nice shadow design joint, colour lacquering at choice.

Finishing:

Construction and frame welded, fronts edged as bonnets and installed without screw connections in view (side screw connection).

Lettering:

Upper area - logo lasered out and backed with acrylic glass and backlit with LED light modules. Below equipped with base, colour painting like shadow gap. Remaining lettering up to 4 colours in digital print or with foil text.

Lighting:

Is provided by modern and energy-saving LED technology (6500 Kelvin, approx. 35-120 watts) Lettering elements such as logo and texts are backed with acrylic glass and illuminated through.

With 2x recessed floor lights, stainless steel, silver, 0.5 m connection cable, recessed housing, incl. LED power supply unit and connection box, 220-240 V/AC alternating voltage, 50/60 Hz, 6 watts, 6500 K/cold white, luminous flux 590 lm,LED module 35/45 degrees asymmetrical, IP67, fixed.

Mounting:

Ground mounting is via two anchor tubes on the pylon, which are cast in a sleeve foundation. On request also available with two flange plates for an existing foundation at extra cost (recommended fixing set included in delivery).

Packaging/delivery:

Pre-assembled or partially assembled packed on pallet. Please enquire about shipping costs.

Change requests and special solutions:

For individual requests and ideas, feel free to write to us or contact us directly. You will receive a great concept and a non-binding offer.

Photo reference:

Photos only represent an example of the product. The product is created similarly. Deviations in size, design and colour are technically possible.

Important Note on Disposal According to the Electrical and Electronic Equipment Act (ElektroG)

The Electrical and Electronic Equipment Act regulates that electrical waste should not be disposed of in household waste but should be collected and recycled separately. Electrical and electronic waste is one of the fastest-growing waste streams in the EU. As a manufacturer and retailer, we offer you the option to return your old devices to us or to collection points located in your area. You can send the devices purchased from us back to us with postage paid. We will ensure their proper disposal.
