Stand Sign with Lightbox, H=2750 mm

Technical Description | Features:

Material:
Stand sign with aluminium posts and decorative elements painted according to RAL colour codes. Above, an LED-illuminated panel made of aluminium and acrylic glass is integrated between the posts (for logo signage, for example). Below the illuminated panel, an advertising and information sign made of aluminium composite material is attached. Custom signage according to your preference. Please inquire about post painting in custom RAL colours.

Construction:
The structure and illuminated panel are welded together. Acrylic glass hoods are bent and fitted on the sides between the posts, similar to the advertising and information signs, and secured with screws (replaceable).

Signage:
High-performance vinyl lettering with matte protective laminate, UV- and weather-resistant. Design according to your print template.

Illumination:
LED backlight for the upper illuminated panel (in a “V“ shape)
Utilises modern and energy-efficient LED technology (6500 Kelvin, approximately 35-120 watts). Signage elements such as logos and text are backed by acrylic glass and illuminated.

LED Spotlight:
Includes 2x stainless steel silver ground-recessed lights, 0.5 m-connection cable, built-in housing, LED power supply, and junction box. Operates on 220-240 V/AC alternating current, 50/60 Hz, 6 watts, 6500 K/cool white, luminous flux of 590 lm, LED module with 35/45-degree asymmetrical beam angle, IP67, fixed.

Mounting:
The ground fixation is carried out via extended tubes suitable for a sleeve foundation. Optionally, at an additional cost, it can also be fastened with two flange plates for an existing foundation (recommended fastening set included).

Packaging/Delivery:
Partially or fully assembled and packaged on a pallet. Please inquire about shipping costs.

Customisation and Special Solutions:
For individual requests and ideas, feel free to write to us or contact us directly. You will receive a great concept and a non-binding offer.

Photo Disclaimer:
Photos are for illustrative purposes only. The actual product will be created similarly. Deviations in size, design, and colour are possible due to technical constraints.
